Wednesday 12 March 2014

GM1 shutters

The Lumix GH3 was among the first to feature electronic shutter. However, since the shutter reads the image sequentially row for row rather slowly, causing a number of artefacts, the feature is not very useful.

The Lumix GM1 also has the electronic shutter, of course, but is it any different? In this article I will look into it.

Speed of shutter curtains

One way to test the speed of the electronic shutter is to take a photo at a fast shutter speed in artificial light. For about a century or so, people have been using incandescent light bulbs for electronic indoor lightning. Even when used on alternating current (AC), the light is stable. Since the filament is heated, it emits light also when the alternating current is at zero.

However, traditional incandescent light bulbs are now being replaced with the energy saving fluorescent light bulbs. They tend to flicker at 100Hz (in Europe) or at 120Hz (in the US). The lights don't flicker at 50Hz and 60Hz, as you might expect. This is since during each period, the electrical current reaches two peaks, see the illustration below:

To understand how this is related to the speed of the shutter curtains, consider the illustration below. It shows what happens when the mechanical curtain shutter is engaged. Let's say, as an example, that the curtain shutters move across the sensor in 1/100s, and that the exposure is 1/500s. It would go like this:

1. As the exposure commences, the first shutter curtain starts moving downwards, exposing the sensor.

2. After the duration of the shutter speed has expired, the second shutter starts moving downwards. In my example, the shutter curtains travel across in 1/100s, so the shutter speed of 1/500s corresponds to 1/5 total opening.

3-6. Both shutter curtains continue downwards, exposing each row of the sensor for a total of 1/500s.

7. As the second curtain shutter closes, the exposure is finalised.

If the scene is stable during this operation, there are no issues. However, if the subject moves horizontally, it will be skewed. Or if the light flickers, you will get horizontal stripes.

The electronic shutter works in the same way. There are no mechanical curtains with the electronic shutter, of course. But you could visualize the process in the same way.

The first shutter opening corresponds to the first sensor rows initializing, getting ready for collecting the exposure. And the second shutter corresponds to stopping the exposure, row for row.

The test

Since I am in Europe, my lights flicker at 100Hz. Here are some images taken in this light:

CameraElectronic shutterMechanical shutter
Lumix GM1

ISO 25600, f/2.8, 1/640s

ISO 25600, f/2.8, 1/640s
Lumix GH3

ISO 1600, f/2.8, 1/640s

ISO 12800, f/2.8, 1/200s

These results are quite easy to explain. With the Lumix GM1, I get four stripes horizontally. Each stripe corresponds to 1/100s, hence, the total exposure takes 1/25s.

The mechanical shutter is faster, and there appears to be one light cycle during the exposure, corresponding to a shutter curtain speed of 1/100s.

The Lumix GH3 has a much slower electronic shutter. There are ten stripes in the image, which means that the exposure takes 1/10s. This causes a number of problems, making the electronic shutter mode fairly useless.

The mechanical shutter of the GH3 is of course a lot faster. In this article, I have measured the shutter curtain speed to be around 1/230s.

Here are the results:

CameraElectronic shutterMechanical shutter
Lumix GM11/25s
Lumix GH31/10s1/230s
Lumix GX71/15s1/500s?
Lumix GH41/25s?1/500s?


So what does this mean? First of all, using the electronic shutter can cause various artefacts. If you take pictures indoor in fluorescent light, you could risk getting stripes. To avoid them, use a shutter speed which corresponds to the flicker frequency. If you are in an NTSC country, like the US, set the shutter speed to 1/120s, 1/60s or 1/30s, or slower. That should be safe. In a PAL country, use 1/100s, 1/50s, 1/25s, or slower.

If you have moving subjects, you could also risk getting skewed pictures with the electronic shutter. Even the mechanical GM1 shutter is slower than usual, and could give you slightly distorted images. Here are a couple of examples. The vehicles are moving at approximately the same speed:

Electronic shutter Mechanical shutter
ISO 800, 28mm, f/5.6, 1/500s ISO 400, 28mm, f/5.6, 1/250s

As you see, both shutters are prone to distorting moving objects, but the mechanical shutter is generally the most safe.

In addition, the relatively slowly moving shutter curtains means that the flash sync speed is rather poor. You can use a max shutter speed of 1/50s while using the flash. This limits the possibility to use fill flash in combination with a large aperture outdoors. You would typically miss this if you want to take a backlit portrait outdoors using a large aperture lens, like the Lumix G 20mm f/1.7. Otherwise, a max flash sync speed of 1/50s is not that much of a problem.

Image quality

An interesting Panasonic sensor data sheet has popped up. We don't know for sure but it is widely believed that this sheet describes the sensor sitting in the Lumix GX7 and GM1. Some also speculate that it will be in the upcoming Lumix GH4.

The sensor sheet states that a full scan of the sensor can be done in 1/14.7s (12 bits) or 1/22.5s (10 bits). The latter is consistent with my measurement in this article. This finding leads us to think that the image quality may suffer when using the electronic shutter mode. After all, you only get 10 bits readout from the sensor, rather than 12 bits (presumably) with the mechanical shutter.

To test this, I have taken the same image with the electronic and mechanical shutters. All the images were taken at ISO 400, 1s, f/4:

CameraElectronic shutterMechanical shutter
Lumix GM1
Lumix GH3

Are there any differences? Hard to say with these images. We can take a closer look at the shadow areas. I developed the RAW images in Silkypix, and lifted the shadows 3 stops. Click to enlarge the picture:

Based on this test, it is actually quite clear to me that there is more noise in the shadows in the images taken with the electronic shutter, for both cameras.

But keep in mind that this was a pretty extreme example: I did lift the exposure by three stops, which one would certainly not do often.

What this means in practice, is that using the electronic shutter probably limits the effective dynamic range. This could matter when you have both dark and bright areas in the frame at once: Using the electronic shutter could limit your possibility to see details in the shadows. So if the dynamic range of the scene is wide, don't use the electronic shutter.

Other cameras

The Lumix GH3, G5 and G6 all have the slower electronic shutter, reading the sensor at approx 1/10s.

Newer cameras like the Lumix GX7 (1/15s) and GM1 (1/25s) have the improved, faster electronic shutter. The GX7 also has a faster mechanical shutter unit, capable of 1/360s flash sync.

The upcoming Lumix GH4 is said in Panasonic marketing material to have an electronic shutter capable of "faster than 50ms readout", which corresponds to faster than 1/20s, i.e., consistent with my GM1 finding above. It could very well be that these cameras share electronic shutter technology.

So far, no Olympus cameras have the silent, electronic shutter option.


The electronic shutter of the Lumix GM1 has improved a lot, making it much more useful. The risk of getting serious distortions due to the rolling shutter effect is much smaller with the GM1.

There are indications that the dynamic range is more limited in the electronic shutter mode, due to only reading 10 bits of colour information from the sensor, as opposed to 12 bits when using the mechanical shutter.

Panasonic chose to optimize the GM1 mechanical shutter for size, silence, and less vibrations. Mostly, this is a good thing. There are some limitations in terms of what kind of flash images you can take. And you can risk some rolling shutter artefacts with fast moving objects. Otherwise, what you get is a very silent shutter with little risk of shutter shock.

All in all, I think Panasonic have struck a nice balance here. When people see the Lumix GM1, they expect a light and stealthy camera, not a speed monster. People who are interested in a sports camera would not buy the GM1 anyway, they would probably be better off with a GH3 or a G6.

Further reading

Image quality comparison between the GM1 and GH3.

Autofocus during video comparison between the GM1 and GH3.
